| Parameter | Specification |
|---|---|
| Product Name | Surface Thermocouple |
| Thermocouple Type | K, J, T, E |
| Probe Structure | Flat / Patch / Surface sticking type |
| Probe Material | Stainless steel / Copper / Kapton |
| Temperature Range | -50℃ ~ 600℃ (depends on model) |
| Accuracy | Class 1 / Class 2 |
| Response Time | Fast (≤1 second) |
| Cable Type | Teflon / Silicone insulated lead wire |
| Cable Length | 1m, 2m, 3m, 5m (customizable) |
| Installation | Adhesive / Magnetic / Clamp mounting |
| Application | Surface temperature measurement for molds, pipes, motors, metal sheets, heating equipment |
Advantages
- Fast response speed, suitable for real-time surface temperature detection.
- Thin and flexible structure, can be attached to flat, curved or irregular surfaces.
- Easy installation with adhesive, magnetic or clamp mounting, no need for drilling.
- Wide compatibility with various thermocouple types (K, J, T, E).
- Compact size and lightweight, ideal for limited space.
Disadvantages
- Only used for surface temperature measurement, not for immersion or liquid environment.
- Lower maximum temperature than armored probe type thermocouples.
- Measurement accuracy affected by installation tightness and contact condition.
- Poor durability under high vibration or harsh mechanical impact.
Applications
- Mold temperature measurement in plastic and rubber industry.
- Pipe, wall and metal sheet surface temperature monitoring.
- Heating plate, roller and motor surface detection.
- Electronic equipment and PCB surface temperature test.
- Food processing, packaging machinery and HVAC equipment.
